Aviation Kerosene
JP-5 (NATO F-44)
High flash point kerosene-type jet fuel produced to MIL-DTL-5624 for naval and military aviation. Supplied in bulk cargoes for government, defence and fuel distribution customers.
Request a Quotation View SpecificationsProduct Overview
JP-5 is a military turbine fuel with a flash point of 60°C minimum, much higher than commercial Jet A-1. That makes it safer to store and handle on ships and aircraft carriers. Its NATO code is F-44.
High Flash Point
Flash point of 60°C min reduces fire risk in shipboard storage and fuelling.
Military Specification
Produced to MIL-DTL-5624 and supplied with a certificate of quality for each batch.
Additized
Contains fuel system icing inhibitor, corrosion inhibitor and static dissipator additives as the specification requires.
Inspected Cargo
Quality and quantity verified by an independent inspector at loading and discharge.
Specifications
Limits based on MIL-DTL-5624 for JP-5. The final specification is agreed in the contract and confirmed by the independent inspector's report.
| Parameter | Limit | Test method |
|---|---|---|
| Density @ 15°C (kg/m³) | 788 – 845 | ASTM D1298 / D4052 |
| Flash point (°C) | min 60 | ASTM D93 |
| Freezing point (°C) | max -46 | ASTM D2386 / D5972 |
| Distillation, 10% recovered (°C) | max 205 | ASTM D86 |
| Distillation, final boiling point (°C) | max 300 | ASTM D86 |
| Viscosity @ -20°C (mm²/s) | max 8.5 | ASTM D445 |
| Net heat of combustion (MJ/kg) | min 42.6 | ASTM D4529 / D3338 |
| Smoke point (mm) | min 19 | ASTM D1322 |
| Aromatics (% v/v) | max 25.0 | ASTM D1319 |
| Naphthalenes (% v/v) | max 3.0 | ASTM D1840 |
| Total sulphur (% m/m) | max 0.40 | ASTM D1266 / D4294 |
| Mercaptan sulphur (% m/m) | max 0.002 | ASTM D3227 |
| Total acidity (mg KOH/g) | max 0.015 | ASTM D3242 |
| Existent gum (mg/100 mL) | max 7.0 | ASTM D381 |
| Copper strip corrosion (2 h @ 100°C) | max No. 1 | ASTM D130 |
| Thermal stability (JFTOT, 2.5 h @ 260°C) | pass | ASTM D3241 |
| Fuel system icing inhibitor (% v/v) | 0.10 – 0.15 | ASTM D5006 |
Approved additives are added as the specification requires. Cargo quality is established by independent inspection at the load port.
Applications
Used by navies and military air forces, and by operators who need a high flash point turbine fuel.
Naval Aviation
Fuel for carrier-based aircraft and shipboard helicopters.
Air Forces
Fuel for military jet and turboprop aircraft.
Distributors
Resale to authorised government and defence fuel suppliers.
Storage
Terminal and tank farm inventory for regional supply.
Commercial Terms
- Quantity: bulk cargoes by tanker
- Payment: as agreed in the contract
- Inspection: independent inspector at load and discharge
- Documents: ICPO, SCO, CI, PPOP
Delivery Terms
Loading ports worldwide, including Rotterdam, Houston, Jurong, Al Fujairah and Qingdao.
Ready to Buy JP-5?
Send your ICPO with the quantity, discharge port and delivery term. We reply with the procedure and the commercial offer.
Send Your ICPO
